Lateral Lever - Detent 3 Position

The three-position mechanical lateral lever valve operates from a central starting position. The handle can be moved in either direction and will stay in that positions until it is returned to the center by moving the handle back.

The series 200 consist of a broad range of valves with various type of actuation.
Due to their special construction with a balanced spool, these valves can be used interchangeably as 3 ways or 5 ways.
The 3 ways can be used normally closed or normally open and the 5 ways can be fed through the exhausts 3 and 5 with different pressures
according to the need.
The spool, as it is moving, isolates the connections without being affected by the inlet pressure.

Max working pressure: 10 Bar

Temperature: -5 to +70°

SKU	Description	Port Size	Type	Configuration	Price	Stock
PN-212.53.31.9	3 Position Lever Valve Detent	1/2"	5/3	Closed Centre	£182.88 exc VAT	In stock Available to Order
PN-228.53.31.9/2	3 Position Lever Valve Detent	1/8"	5/3	Closed Centre	£49.10 exc VAT	In stock Available to Order
PN-228.53.32.9/2	3 Position Lever Valve Detent	1/8"	5/3	Open Centre	£44.85 exc VAT	In stock Available to Order
PN-224.53.31.9/2	3 Position Lever Valve Detent	1/4"	5/3	Closed Centre	£74.23 exc VAT	In stock Available to Order
