Lateral Lever - 2 Position

The two-position mechanical lateral lever valve functions by pushing the lever in one direction and returning it to the original position by pulling the lever back.

The series 200 consist of a broad range of valves with various type of actuation.
Due to their special construction with a balanced spool, these valves can be used interchangeably as 3 ways or 5 ways.
The 3 ways can be used normally closed or normally open and the 5 ways can be fed through the exhausts 3 and 5 with different pressures
according to the need.
The spool, as it is moving, isolates the connections without being affected by the inlet pressure.

Max working pressure: 10 Bar

Temperature: -5 to +70°

SKU	Description	Port Size	Type	Price	Stock
PN-212.32.9	G1/2 3/2 Lateral Lever Valve 2 Position	1/2"	3/2	£154.31 exc VAT	In stock Available to Order
PN-212.52.9	G1/2 5/2 Lateral Lever Valve 2 Position	1/2"	5/2	£167.10 exc VAT	In stock Available to Order
PN-224.32.9/2	G1/4 3/2 Lateral Lever Valve 2 Position	1/4"	3/2	£124.74 exc VAT	In stock Available to Order
PN-224.52.9/2	G1/4 5/2 Lateral Lever Valve 2 Position	1/4"	5/2	£83.90 exc VAT	In stock Available to Order
PN-228.32.9/2	G1/8 3/2 Lateral Lever Valve 2 Position	1/8"	3/2	£39.62 exc VAT	In stock Available to Order
PN-228.52.9/2	G1/8 5/2 Lateral Lever Valve 2 Position	1/8"	5/2	£46.44 exc VAT	In stock Available to Order
