Pilot Differential External

Pilot operated differential external spool valve

The series 200 consist of a broad range of valves with various type of actuation.
Due to their special construction with a balanced spool, these valves can be used interchangeably as 3 ways or 5 ways.
The 3 ways can be used normally closed or normally open and the 5 ways can be fed through the exhausts 3 and 5 with different pressures
according to the need.
The spool, as it is moving, isolates the connections without being affected by the inlet pressure.

Max working pressure: 10 Bar

Temperature: -5 to +70°

Pilot port size: G1/8"

Minimum piloting pressure: 2.5 Bar
