32mm Bore x 25mm Stroke D/A Cylinder Magnetic Stainless Piston Rod

ISO 15552 Cylinders

  • SKU: PN-1320.32.25.01
  • Price:£91.75exc VAT
  • Stock:

    In stock

    Available to Order

This series of pneumatic cylinders is manufactured according to ISO 6431 standards adapted to VDMA 24562 and CNOMO/AFNOR 49003 that gaurantee the interchangeability of the cylinders even without mounted anchoring.

Construction CharacteristicsOperational Characteristics
End Caps: from Ø32 to Ø125: UNI 5079 aluminium alloy casting painted black by cataphoresis from Ø160 to Ø200: UNI 3051 aluminium chilled painted black by cataphoresisFluid: Filtered air. No lubrication needed, if applied it shall be continuous.
Rod: Stainless SteelPressure: Max 10 bar
Barrel: Oxidised aluminiumOperating Temperature: -5 °C - +70 °C with standard seals
Cushion bushings: Hardened aluminium
Rod-guide bushing: Self-lubricating sintered bronze
Piston: Vulcanized rubber block on steel core
Seals: Standard: NBR Oil resistant rubber, PUR Piston rod and cushion seals



Seal Kits are available
